OSA Demolition Demolition Multisystem

Demolition Multi System - Rotational

/

Excavator

Product Overview

RV hydraulic rotating pulverizers have been manufactured with HARDOX 400 to resist wear and tear and they have a regenerative circuit for a fast jaw opening and closing. Hydraulic rotation (360°) gives a precise positioning of the pulveriser in every working condition.

Key Features

  • An innovative system “PRV” (Pressure Relief Valve) to protect the pulveriser from high pressure
  • Pulveriser in HARDOX 400
  • A reversed cylinder to protect the rod
  • A fast valve
  • Interchangeable blades
  • An innovative interchangeable teeth system

Specifications

Specification Unit RV 6 RV 10 RV 16 RV 20 RV 25 RV 30 RV 40 RV 60 RV 80 RV 110
OPENING (A) MM 520 630 790 840 880 1010 1130 1280 1350 1720
LENGTH (B) MM 1600 1815 2120 2300 2400 2660 2850 3230 3400 3800
DEPTH (C) MM 340 390 500 500 530 530 550 660 620 650
EXCAVATOR WEIGHT KG 7-12 9-11 15-20 20/26 25-32 30-40 38-55 50/80 70/90 90/120
EQUIPMENT WEIGHT KG 660 1105 1710 2000 2500 2970 3940 6000 7800 9950
OIL PRESSURE BAR 250 310 340 340 340 340 340 340 340 340
OIL CAPACITY L/min 80-100 100-150 150-220 210-260 250-300 280-320 300-350 330/400 400/500 500/600
ROTATION OIL PRESSURE BAR 60 120-130 120-130 120-130 120-130 120-130 120-130 120/130 120/130 120/130
ROTATION OIL CAPACITY L/min 20 20-30 20-30 20-31 50-60 50-60 50-60 50/60 70/80 70/80
OPERATING TOTAL WEIGHT KG 710 1200 1850 2200 2700 3270 4300 6500 8500 10945
