HARRYBILT ENGINEERING LIGHT WEIGHT RAIL GRAB

Grab

/

Excavator

Product Overview

The Rail Grab has been designed by Harrybilt Engineering to pick up and manoeuver lengths of rail up to 1700kg in weight.

The grab includes 2 hydraulically operated jaws to grip and hold the rail.  The hydraulic cylinders controlling these jaws are fitted with counterbalance valves to keep the rail secure even in the event of hose failure.

Key Features

  • Little or no micro cracking of the ground outside the excavation line. (Cracking from hammers has been shown to reach up to 2m, depending on rock type). This can cause issues with existing infrastructure.
  • Minimised overbreak of trench line.
  • Minimal disturbance of trench face making for a safer more intact trench.
  • Lower noise impact than other methods.
  • Lower vibration impact.
  • Ability to reuse the material onsite as hardfill, thus reducing waste and increasing site efficiency.
  • Extremely reliable tools and Antraquip also have a range of Soft Soil mixing attachments which have used in NZ for Mud-Crete.

Specifications

LIGHT WEIGHT RAIL GRAB
Attachment Weight (KG) 170
Oil flow (LPM) N/A
Oil Pressure (PSI) 1000-2600 PSI
Excavator Class (Tons) 8t

Industry

Type

Machine
