Key Features
Navigate Obstacles Effortlessly
Adapt to any screening challenge effortlessly with interchangeable modular Hardox wear plate or high carbon steel mesh screening panels, ensuring versatility like never before.
Productivity Unbound
Size versatility meets productivity excellence. From 8-tonne minis to heavy-duty 32-tonne+ machines, the Boss Rotary Screening (BRS) range ensures that every excavator can unleash its full potential.
Profitability To Unprecedented Levels
Stop settling for minimal output and start dominating your industry. With the Boss Rotary Screening Bucket, you’ll tackle jobs like a BOSS, driving efficiency and profitability to unprecedented levels.
Specifications
| BRS-80S 9 | BRS-120S | BRS-200S | BRS-300S | |
| EXCAVATOR WEIGHT | ≥8 | ≥13 | ≥22 | ≥30 |
| LOADER WEIGHT | ≥2.6 | 6-12 | 9-15 | 15-35 |
| WEIGHT | 860Kg | 1,540Kg | 2,440Kg | 2,550Kg |
| Load Capacity (SAE) | 0.7m3 | 1.3m3 | 2.1m3 | 2.8m3 |
| Basket Depth (C) | 690mm | 790mm | 980mm | 1,040mm |
| Basket Width (D) | 840mm | 1,170mm | 1,560mm | 1,700mm |
| Oil Flow (l/min) | 50/70 | 40/80 | 40/80 | 40/80 |
| Pressure (bar) | 100/120 | 200/220 | 200/220 | 200/220 |
| Speed (RPM) | 18/24 | 18/35 | 18/35 | 18/35 |
| Screen Apertures (mm) | 5-80 | 5-140 | 5-140 | 5-200 |
| BRS Depth (A) | 1,480mm | 1,950mm | 2,250mm | 2,600mm |
| BRS Height (B) | 1055mm | 1460mm | 1890mm | 2000mm |
| BRS Width (L) | 900mm | 1200mm | 1600mm | 1750mm |
