- Designed and manufactured in Italy exclusively for Boss Attachments.
- Double Plate Connection. Attach to your Excavator or Loader.
- Solid, durable and characterized by the now recognizable clean lines designed to resist wear and high stresses in the toughest working conditions.
- Constructed entirely from SSAB HARDOX and STRENX materials.
- Full Floating planetary drive systems.
- High Radial & Axial load resistant basket support system.
- Variable speed high torque motor with cushion stop.
- Unique and innovative conical shaped basket.
- Interchangeable modular Hardox wear plate or high carbon steel mesh screening panels.
|
BRS-80S 9 |
BRS-120S |
BRS-200S |
BRS-300S |
| EXCAVATOR WEIGHT |
≥8 |
≥13 |
≥22 |
≥30 |
| LOADER WEIGHT |
≥2.6 |
6-12 |
9-15 |
15-35 |
| WEIGHT |
860Kg |
1,540Kg |
2,440Kg |
2,550Kg |
| Load Capacity (SAE) |
0.7m3 |
1.3m3 |
2.1m3 |
2.8m3 |
| Basket Depth (C) |
690mm |
790mm |
980mm |
1,040mm |
| Basket Width (D) |
840mm |
1,170mm |
1,560mm |
1,700mm |
| Oil Flow (l/min) |
50/70 |
40/80 |
40/80 |
40/80 |
| Pressure (bar) |
100/120 |
200/220 |
200/220 |
200/220 |
| Speed (RPM) |
18/24 |
18/35 |
18/35 |
18/35 |
| Screen Apertures (mm) |
5-80 |
5-140 |
5-140 |
5-200 |
| BRS Depth (A) |
1,480mm |
1,950mm |
2,250mm |
2,600mm |
| BRS Height (B) |
1055mm |
1460mm |
1890mm |
2000mm |
| BRS Width (L) |
900mm |
1200mm |
1600mm |
1750mm |
